| Imaging Device |
			3 x 1/3" Exmor CMOS |


			| Signal to Noise Ratio |
			54 dB |


			| Zoom Ratio |
			20x |


			| 35mm Equivalent Focal Length |
			29.5 - 590mm |


			| ND Filters |
			OFF, 1/4, 1/16, 1/64 |


			| Gain Selection |
			-3, 0, 3, 6, 9, 12, 18 dB |


			| Sensitivity |
			F9 (typical) at 2000 lx, 89.9% reflectance |


			| Slow Shutter |
			2, 3, 4, 5, 6, 7, 8, 16, 32, and 64-frame accumulation |


			| File Format |
			UDF, FAT |


			| Video Recording Format |
			UDF Mode (HD Recording)
			MPEG HD422 (MPEG-2 422P@HL):
			CBR, 50 Mb/s

			MPEG HD420 (1440x1080, MPEG-2 MP@HL):
			HQ mode (VBR, maximum bit rate: 35 Mb/s)
			SP mode (CBR, 25 Mb/s) - playback only
			LP mode (VBR, maximum bit rate: 18 Mb/s) - playback only

			UDF Mode (SD Recording)DVCAM (CBR, 25 Mb/s)

			FAT Mode (HD Recording)
			MPEG HD420 (1920x1080, MPEG-2 MP@HL):
			HQ mode (VBR, maximum bit rate: 35 Mb/s)
			SP mode (CBR, 25 Mb/s)

			Fat Mode (SD Recording)
			DVCAM (CBR, 25 Mb/s) |


			| Frame Rates |
			XDCAM HD422 at 50Mbps:
			1080/59.94i, 1080/29.29p, 1080/23.98p, 1080/50p, 1080/25p
			720/59.94p, 720/29.97p, 720/23.98p, 720/50p, 720/25p |


			| Audio Recording |
			UDF Mode (HD Recording)
			MPEG HD422 (MPEG-2 422P@HL):
			4 channels, 48KHz, 24-bit LPCM

			MPEG HD420 (1440x1080, MPEG-2 MP@HL):
			4 channels, 48KHz, 16-bit LPCM

			UDF Mode (SD Recording)DVCAM: 4 ch/16 bits/48 kHz

			FAT Mode (HD Recording)
			MPEG HD420 (1920x1080, MPEG-2 MP@HL):
			2 channels, 48KHz, 16-bit LPCM

			FAT Mode (SD Recording)
			DVCAM: 2 channels, 48 KHz, 16-bit LPCM |


			| Recording/Playback Time |
			UDF Mode (HD Recording)
			50 Mb/s MPEG HD422 (MPEG-2 422P@HL):
			Approx. 120 min with SBS-64G1A (64 GB) memory card
			Approx. 60 min with SBP-32 / SBS-32G1A (32 GB) memory card
			Approx. 30 min with SBP-16 (16 GB) memory card

			35 Mb/s VBR, HQ Mode MPEG HD420 (1440x1080, MPEG-2 MP@HL):
			Approx. 180 min with SBS-64G1A (64 GB) memory card
			Approx. 90 min with SBP-32 / SBS-32G1A (32 GB) memory card
			Approx. 45 min with SBP-16 (16 GB) memory card

			UDF Mode (SD Recording)
			25 Mb/s DVCAM
			Approx. 220 min with SBS-64G1A (64 GB) memory card
			Approx. 110 min with SBP-32 / SBS-32G1A (32 GB) memory card
			Approx. 55 min with SBP-16 (16 GB) memory card

			FAT Mode (HD Recording)
			35 Mb/s VBR, HQ Mode - MPEG HD420 (MPEG-2 MP@HL):
			Approx. 200 min with SBS-64G1A (64 GB) memory card
			Approx. 100 min with SBP-32 / SBS-32G1A (32 GB) memory card
			Approx. 50 min with SBP-16 (16 GB) memory card

			25 Mb/s CBR, SP Mode - MPEG HD 420 (MPEG-2 MP@HL-14):
			Approx. 280 min with SBS-64G1A (64 GB) memory card
			Approx. 140 min with SBP-32 / SBS-32G1A (32 GB) memory card
			Approx. 70 min with SBP-16 (16 GB) memory card

			Fat Mode (SD Recording)
			25 Mb/s DVCAM
			Approx. 220 min with SBS-64G1A (64 GB) memory card
			Approx. 110 min with SBP-32 / SBS-32G1A (32 GB) memory card
			Approx. 55 min with SBP-16 (16 GB) memory card |


			| Recording Media |
			2 x SxS Express 34 Cards |


			| Inputs |
			2 x XLR-type 3-pin (female): line, mic, mic +48 V selectable
			1 x BNC (switchable to Video Out), 1.0 Vp-p, 75?
			1 x BNC, Timecode In (switchable to TC Out), SMPTE-12M-2008, 0.5-1.8 Vp-p, 10k?) |


			| Outputs |
			1 x A/V out jack: 10 pin connector
			1 x BNC, (switchable to Genlock In), HD-Y / Composite switchable, 1.0 Vp-p, 75?
			1 x BNC, HD/SD switchable, SMPTE-292M/259M
			1 x BNC, Timecode Out (switchable to TC In), SMPTE-12M-2008, 1.0 Vp-p, 10k? |


			| USB 2.0 |
			1 x mini-B |


			| IEEE-1394 |
			1 x 4-pin, HDV (HDV 1080i) / DV input/output, S400 |


			| Earphone |
			1 x Mini-jack (stereo) |


			| Built-in Speaker |
			Monaural, 250 mW |


			| Viewfinder |
			Electric Viewfinder (EVF)
			Approx 1.2 million pixels
			852 x 3 x 480 (HxRGBxV) |


			| LCD Monitor |
			3.5" (8.9 cm) color LCD
			852 x 3 x 480 (HxRGBxV)
			Aspect Ratio: 16:9 |


			| Built-In Microphone |
			Omni-directional stereo electret condenser |


			| Wi-Fi |
			Yes |


			| Humidity |
			10 to 90% (relative humidity) |


			| Storage Temperature |
			-4 to 140&def;F (-20 to 60F) |


			| Operating Temperature |
			32 to 104F (0 to 40C) |


			| Power Requirements |
			12 VDC |


			| Dimensions (WxHxD) |
			6.77 x 6.46 x 12.83" (17.2 x 16.4 x 32.6 cm) (without protrusions) |
